Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Scissor Components
22 GS
™
-84 • GS
™
-90 Part No. 1306587GT
Non
-steer End
Steer End
1 Platform centering link
2 Number 3 inner arm
3 Number 3 center pivot pin (Qty. 2)
4 Number 3 pivot pin (non-steer end)
5 Number 2 outer arm
6 Number 2 inner arm
7 Number 2 pivot pin (non-steer end)
8 Number 1 inner arm
9 Lift cylinder barrel-end pivot pin
10 Number 1 pivot pins (non-steer end)
11 Number 3 outer arm
12 Lift cylinder rod-end pivot pin
13 Number 3 pivot pin (steer end)
14 Number 2 center pivot pin (Qty. 2)
15 Number 2 pivot pin (steer end)
16 Number 1 outer arm
17 Number 1 center pivot pin (Qty. 2)
18 Chassis centering link
19 Number 1 pivot pins (steer end)
