Service and Repair Manual June 2021
Manifolds
82 GS
™
-84 • GS
™
-90 Part No. 1306587GT
7-2
Function Manifold Components - Models without Outriggers
The function manifold is located in the chassis tray on the ground controls side of the machine.
Index
No.
Description
Schematic
Item
Function
Torque
1
Check valve
, 5 psi / 0.3 bar AA
Platform down circuit
40 - 45 ft-lbs
54 - 61 Nm
2
Diagnostic port
AB
Pressure Circuit
3
Relief valve, 350
0 psi / 241.3 bar AC
System relief
25 ft-
lbs / 34 Nm
4
Proportional solenoid valve
AD
All functions
46 - 54 ft-lbs
62 - 73 Nm
5
Relief valve, 200
0 psi / 138 bar AE
Steer
circuit 50 ft-
lbs / 68 Nm
6
Diagnostic port
AF
Pressure Circuit
7
Solenoid valve,
3 position 4 way AG
Platform up/down
30 - 35 in-lbs
3 -
4 Nm
8
Solenoid valve,
3 position 4 way AH
Steer left/right
45 ft-lbs
/ 61 Nm
9
Orifice Plug, 0.15
0 inch / 3.8 mm AI
Platform down circuit
10
Flow regulator valve,
0.
1 gpm / 0.38 L/min
AJ
Bleeds off proportional valve to tank
33 - 37 ft-lbs
45 - 50 Nm
