Service and Repair Manual June 2021
Specifications
10 GS
-84 • GS
-90 Part No. 1306587GT
Deutz TD 2.2 L3 Engine
Displacement
134 c
u. in
2,2 l
iters
Number of cylinders
3
Bore and Stroke
3.6 x 4.3 i
nches
92 x 110 m
m
Horsepower net i
ntermittent
@ 260
0 rpm
49 h
p
36 k
W
Induction system
turbocharged
Firing order
1 - 2 -
3
Low idle, standby
1000 r
pm
Low idle, function enable
1500 r
pm
High idle
2400 r
pm
Governor
electronic
Lubrication system
Low ash oil required
Oil pressure, hot (
@ 2000 rpm)
40 to 60 p
si
2,8 to 4,1 b
ar
Oil capacity (including filter)
8 q
uarts
7,6 l
iters
Oil viscosity requirements
-
22°F to 86°F / -30°C to 30°C
5W-
30
(synthetic)
-
4°F to 104°F / -20°C to 40°C 10W-
40
Above 5°F /
-15°C 15W-
40
Unit ships with 15W
-40. Extreme operating
temperatures may require the use of alternative engine
oils. For oil requirements, refer to the Engine Operator
Manual for your engine.
Oil temperature switch
Installation torque
8 - 18 ft-
lbs
11 -
24 Nm
Temperature switch poi
nt
257°F
125°C
Oil Pressure switch
Installation torque
8 - 18 ft-
lbs
11 -
24 Nm
Pressure switch point
17.4 p
si
1,2 b
ar
Fuel requirement
For fuel requirements, refer to the engine Operator
Manual for your engine.
Engine coolant capacity
2.2 gallons
8,3 liters
Unit ships with Ethylene Glycol engine coolant. Consult
your
local supplier for compatibility before mixing
alternative engine coolants.
Starter motor
Current draw, normal load
140 -
200A
Cranking speed
250 - 350 r
pm
Battery
Engine starting and control system
Type
12V DC, Group 31
Quantity
1
Battery
capacity, maximum
1000A
Reserve capacity @ 25A rate
200 Minutes
Alternator output
95A @ 14V DC
