Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Electrical Component and Wire Color Legends
160 GS
™
-84 • GS
™
-90 Part No. 1306587GT
Item
Description
B1
Battery
BN
Button
BN2
Engine start (PCON)
BN3
Starting aid (PCON)
BN4
High idle (PCON)
BN5
Horn (PCON)
BN6
High torque (PCON)
BN7
Generator (option) (PCON)
BN9
Lift enable (PCON)
BN14
Fuel select (PCON)
BN20
Auto
level (PCON)
BN21
Right rear outrigger (PCON)
BN22
Left rear outrigger (PCO
N)
BN23
Auxiliary down enable (GCON)
BN24
Right front outrigger (PCON)
BN25
Function enable (PCON)
BN26
Left front outrigger (PCON)
BN29
High idle (GCON)
BN32
Fuel
select (GCON)
BN33
Platform up/down enable (GCON)
BN34
Platform up (GCON)
BN35
Plat
form down (GCON)
BN91
Auxiliary down (GCON)
C1
Capacitor, 470
0 uF
CB
Circuit breaker
CB2
System power, 20A
CB6
Controls, 7A
CB7
Throttle, 25A (Deutz models)
Item
Description
FB1
Flashing beacon (option)
G
Gauge
G6
Hour meter
GND
Ground
H
Horn or alarm
H1
Alarm (PCON)
H2
Automotive
-style horn
H5
Alarm (GCON)
JC9
Joystick Controller
KS1
Key switch
M
Motor
M2
Auxiliary pump
M3
Engine
starter
M4
Fuel pump
N.C.
Normally Closed
N.O.
Normally Open
P
Power Switch
P1
Emergency stop butt
on (ground)
P2
Emergency stop button (platform)
Item
Description
PS2
Platform Overload Pressure Switch
Q
Solenoid
Q3
High idle
Q8
Fuel shut off
QD
Quick Disconnect
QD3
Control cable to ground
QD4
Control cable to platform
S
Sensor
S7
Level senso
r (models without outriggers)
S8
Level sensor (models with outriggers)
SW
Switch
SW2
Engine oil pressure
SW3
Engine oil temperature
SW6
Steer
left/right
U
Electronic Component
U1
Electronic control module (GCON)
U2
Electronic control module (PCON)
