June 2021 Service and Repair Manual
Platform Overload Components
Part No. 1306587GT GS
™
-84 • GS
™
-90 111
12-3
Down Limit Height
How to Calibrat e the Down Limit Height
How to Calibrate the Down Limit
Height
Note: Perform this procedure on a firm, level
surface with the machine in the stowed position
unless otherwise instructed.
1 Open the ground controls compartment and
locate the level sensor.
2 Start the engine from the ground controls.
3 Push and hold the level to the side until an
audible alarm is heard.
4 Raise the platform until it stops.
5 Push in the red Emergency Stop button to the
off position.
6 Measure the distance between the surface
and the platform floor.
-3384, GS-3390
93 - 102 i
236 - 259 c
-4390
112 - 124 i
284 - 315 c
-5390 133 - 143 i
338 - 363 c
Result: Platform height is within range.
Adjustment not required.
Result: Platform height is not within range.
Continue with procedure.
Note: The Genie
®
Tech Pro™ Link will required to
adjust the platform down limit height.
7 Connect the Tech Pro Link to the machine.
8 Turn the key switch to ground control and pull
out the red Emergency Stop button to the on
position at both ground and platform controls.
9 Go to Settings / Calibration / DLS Percetage.
Increase or decrease the setting between
3.0% - 11%. Repeat this procedure until
platform up stops within the required range.
Note: The default setting is 9.0%.
