June 2021 Service and Repair Manual
Platform Components
Part No. 1306587GT GS
â„¢
-84 • GS
â„¢
-90 21
2-2
Platform Extension Deck
How to Remove the Platf orm Extension Deck
How to Remove the Platform
Extension Deck
Note: Perform this procedure with the platform in
the stowed position and the platform extension
deck(s) fully retracted and locked in position.
Note: If the machine is equipped with the dual
extension deck option, repeat this procedure for
the other platform extension deck.
1 Steer end extension deck: Remove the
platform controls from the platform and lay
them off to the side of the machine.
2 Remove the retaining pins from the four black
plastic railing guides. Lower the railing guides
in the down direction.
3 Remove the mounting fasteners from the
platform extension deck stop brackets at both
sides of the deck.
Note: The platform extension deck stop brackets
are located above the platform V-roller wheels.
4 At the platform extension deck to be removed,
position a fork lift with the forks even with the
bottom of the platform extension deck.
5 Lift the platform extension deck lock handle.
6 Carefully slide the platform extension deck out
until the platform extension deck makes
contact with the carriage on the forklift.
7 Attach a strap from the platform extension
deck railings to the carriage on the forklift to
help support the platform extension deck.
8 Remove the three V-roller and extension deck
lock bracket mounting fasteners from the
extension deck at the tank side of the
machine.
9 Carefully pull the V-roller and extension deck
lock assembly out of the extension deck.
10 Remove the fasteners from the roller wheels
located under the platform extension deck.
Remove the roller wheels.
11 Carefully slide the platform extension deck out
of the platform and place it on a structure
capable of supporting it.
Crushing hazard. The platform
extension will become
unbalanced and fall when
removed from the machine if not
properly supported and secured
to the forklift.
