Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Deutz D 2.9 L4 Engine Fault Codes
130 GS
™
-84 • GS
™
-90 Part No. 1306587GT
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
KWP = Keyword Protocol
SPN
FMI
KWP
Description
51
3
1019
EGR
-Valve, short circuit to
battery
51
3
1024
Position s
ensor error of actuator
EGR
-Valve; signal range check
high
51
3
1226
EGR
-Valve; short circuit to
battery (A02)
51
3
1227
EGR
-Valve; short circuit to
battery (A67)
51
4
1020
EGR
-Valve; short circuit to
ground
51
4
1025
Position sensor error actuator
EGR
-Valve; signal range check
low
51
4
1228
EGR
-Valve; short circuit to
ground (A02)
51
4
1229
EGR
-Valve; short circuit to
ground (A67)
1
4
1232
Actuator error EGR
-Valve;
Voltage below threshold
51
5
1015
Actuator error EGR
-Valve; signal
range check low
51
5
1017
Actuator EGR
-Valve; open load
51
5
1023
Actuator error EGR
-Valve; signal
range check low
51
5
1223
Actuator
EGR-Valve; open load
51
6
1014
Actuator error EGR
-Valve; signal
range check high
51
6
1022
Actuator error EGR
-Valve; signal
range chec
k high
51
6
1224
Actuator EGR
-Valve; over
current
51
6
1230
Actuator error EGR
-Valve;
Overload by
short-circuit
51
7
1016
Actuator position for EGR
-Valve
not plausible
SPN
FMI
KWP
Description
51
11
1231
Actuator error EGR
-Valve;
Power stage ove
r temp due to
high current
51
12
1018
Actuator EGR
-Valve;
powerstage over temperature
51
12
1021
Mechanical actuator defect
EGR
-Valve
51
12
1225
Actuator EGR
-Valve; over
temperature
94
1
474
Low fuel pressure; warning
threshold exceeded
94
1
475
Low f
uel pressure; shut off
threshold exceeded
94
3
472
Sensor error low fuel pressure;
signal range check high
94
4
473
Sensor error low fuel pressure;
signal range check low
97
3
464
Sensor error water in fuel; signal
range check high
97
4
465
Sensor erro
r water in fuel; signal
range check low
97
12
1157
Water in fuel level
prefilter;
maximum value exceeded
100
0
734
High oil pressure; warning
threshold exceeded
100
0
735
High oil pressure; shut off
threshold exceeded
100
1
736
Low oil pressure; warnin
g
threshold exceeded
100
1
737
Low oil pressure; shut off
threshold exceeded
100
3
732
Sensor error oil pressure; signal
range check high
100
4
733
Sensor error oil pressure sensor;
signal range check low
102
2
88
Charged air pressure above
warning thr
eshold
102
2
89
Charged air pressure above shut
off
threshold
102
4
777
Sensor error charged air press.;
signal range check low
