Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Deutz D 2.9 L4 Engine Fault Codes
Part No. 1306587GT GS
™
-84 • GS
™
-90 131
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
KWP = Keyword Protocol
SPN
FMI
KWP
Description
105
0
996
High charged air cooler
temperature; warning
threshold
exceeded
105
0
997
High charged air cooler
temperature; shut off threshold
exceeded
105
3
994
Sensor error charged air
temperature; signal range check
high
105
4
995
Sensor error charged air
tempera
ture; signal range check
low
108
3
412
Sensor error ambient air press.;
signal range check high
108
4
413
Sensor error ambient air press.;
signal range check low
110
0
98
High coolant temperature;
warning threshold exceeded
110
0
99
High coolant temper
ature; shut
off threshold
exceeded
110
3
96
Sensor error coolant temp.;
signal range check high
110
4
97
Sensor error coolant temp.;
signal range check low
111
1
101
Coolant level too low
132
11
1
Air flow sensor load correction
factor exceeding the ma
ximum
drift limit;
plausibility error
132
11
2
Air flow sensor load correction
factor exceeding drift limit;
plausibility error
132
11
3
Air flow sensor low idle
correction factor exceeding the
maximum drift limit
132
11
4
Air flow sensor load correctio
n
factor
exceeding the maximum
drift limit
157
3
877
Sensor error rail pressure; signal
range check high
157
4
878
Sensor error rail pressure; signal
range check low
SPN
FMI
KWP
Description
168
0
1180
Physical range check high for
battery voltage
168
1
1181
Physical range check low for
battery voltage
168
2
47
High battery voltage; warning
threshold exceeded
168
2
48
Low battery voltage; warning
threshold exceeded
168
3
45
Sensor error battery voltage;
signal range check high
168
4
46
Sensor
error battery voltage;
signal range check low
171
3
417
Sensor error environment
temperature; signal range check
high
171
4
418
Sensor error environment
temperature; signal range check
low
172
0
1182
Physical range check high for
intake air
temperature
1
72
1
1183
Physical range check low for
intake air temperature
172
2
9
Sensor ambient air temperature;
plausibility error
172
2
983
Intake air sensor; plausibility
error
172
3
981
Sensor error intake air; signal
range check high
172
4
982
Sensor error i
ntake air sensor;
signal range check low
174
0
481
High low fuel temperature;
warning threshold exceeded
174
0
482
High Low fuel temperature; shut
off threshold exceeded
175
0
740
Physical range check high for oil
temperature
175
0
745
High oil tempera
ture; warning
threshold exceeded
175
0
746
High oil temperature; shut off
threshold exceeded
175
1
741
Physical range check low for oil
temperature
