Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Ground Controls
58 GS
™
-84 • GS
™
-90 Part No. 1306587GT
12 Press the lift function enable button.
13 Press the yellow platform down button to
decrease the drive speed or press the blue
platform up button to increase the drive
speed. Refer to Specifications, Performance
Specifications.
Note: The performance achieved should always be
within specifications.
14 Press the lift function enable button.
15 Push in the ground controls red Emergency
Stop button to the off position.
16 Check the stowed drive speed of the
machine. Refer to Maintenance Procedure in
the appropriate Service or Maintenance
Manual for your machine, Test the Drive
Speed - Stowed Position.
How to Adjust the Hi gh Torque Drive Speed
How to Adjust the High Torque
Drive Speed
Tip
-over hazard. Do not adjust
the lift and/or drive speed higher
than specified in this procedure.
Setting drive speed greater than
specifications could cause th
e
machine to tip over resulting in
death or serious injury.
Note: On machines with software revision B1 or
lower, high torque drive speeds in forward and
reverse are simultaneously adjusted, resulting in
both directions of travel operating at the same
speed.
On machines with software revision C0 or higher,
the high torque forward drive speed and the high
torque reverse drive speed may be adjusted
independent of one another. Refer to Repair
Procedure, How to Determine the Revision Level.
1 Pull out the red Emergency stop button to the
on position at the platform controls.
2 Push in the ground controls red Emergency
Stop button to the off position.
3 Turn the key switch to ground controls.
4 Press and hold both the blue platform up and
yellow platform down buttons. Pull out the red
Emergency Stop button to the on position at
the ground controls.
Result: TUNE SPEEDS is showing in the
diagnostic display window. The ECM is now in
programming mode.
5 Press the lift function enable button.
6 Use the yellow platform down arrow to scroll
to max fwd high torque drive.
Result: MAX FWD HIGH TORQUE DRIVE is
showing in the diagnostic display window.
7 Press the lift function enable button.
