Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Specifications
Part No. 1306587GT GS
™
-84 • GS
™
-90 1
Section 2 Specificati ons
Machine Specifications
Fluid capacities
Hydraulic tank
30 g
allons
114 l
iters
Hydraulic
system (including tank)
GS
-3384 and GS-3390
37.5 g
allons
142 l
iters
Hydraulic system (including tank)
GS
-4390
38.25 g
allons
145 l
iters
Hydraulic system (including tank)
GS
-5390
38.75 g
allons
147 l
iters
Fuel tank
Deutz D 2.9 L4, Ford MSG
-425
20 g
allons
76 l
iters
Fuel tank
Deutz D2011 L03i to serial number
GS84F
-45518 and GS90F-54370
30 g
allons
114 l
iters
Fuel tank
Deutz D2011 L03i from serial number
GS84F
-45519 and GS90F-54371
20 g
allons
20 l
iters
Tires and wheels
High Flotation,
air-filled and foam-filled (all models)
Tire size
33/16LL500
Tire ply rating
10
Tire diameter x Tire width
33 in x 16 i
n
83.8 cm x 41 c
m
Wheel diameter x width
19.5 in x 14 i
n
49.5 cm x 35.6 c
m
Weight, foam filled
419 lbs (+/- 10 l
bs)
190 kg (+/- 4.5 k
g)
Weight, air
-filled
157 l
bs
71.2 k
g
Pressure, air
-filled
38 p
si
2.6 b
ar
Rough Terrain, foam-filled (GS-90)
Tire size
LSW 305-
546 NHS
Tire ply rating
10
Tire weight, new foam
-filled
(minimum) (Rough terrain)
265 l
bs
120 k
g
Tire
diameter x width
33 in x 12 i
n
83.8 cm x 30 c
m
Rough Terrain, foam
-filled (GS-84)
Tire size
51S3D1-
16.5 NHS
Tire ply rating, minimum
8
Tire diameter x width
30.8 in x 10.4 i
n
78.2 cm x 26.4 c
m
Weight, new foam
-filled
(minimum)
(Rough terrain)
224 l
bs
101.6 k
g
Weight, new foam
-filled
(minimum)
(Rough terrain, non
-marking)
228 l
bs
103.4 k
g
Tires
and wheels
Wheel lugs
9 @ 5/8-
18
Lug nut torque, dry
125 ft-
lbs
169.5 Nm
Lug nut torque, lubricated
94 ft-
lbs
127.4 Nm
