Traction Manifold Components
The traction manifold is located under the function manifold
Index
No.
Description
Schematic
Item
Function
Torque
1
Flow divider/combiner valve
EA
Controls flow to front and rear
drive motors
95 - 100 ft-lbs
129 - 135 Nm
2
Orifice Plug, 0.04
3 inch / 1.1 mm EB
Balances flow from flow
divider/combiner (item EL) to front
drive motors
3
D
iagnostic port EC
Testing "P2" pressure port
4
Orifice Plug, 0.04
6 inch / 1.2 mm ED
Balances flow from flow
divider/combiner (item EK) to rear
drive motors
25 ft-
lbs / 34 Nm
5
Relief valve, 28
0 psi / 19.3 bar EE
Charge pressure circuit
25 - 30 ft-lbs
34 - 41 Nm
6
Solenoid Valve,
2 position 3 way EF
2
-speed motor shift circuit 20 ft-
lbs / 27 Nm
7
Orifice Plug, 0.03
5 inch / 0.9 mm EG
Brake circuit
8
Orifice Plug, 0.04
5 inch / 1.1 mm EH
2
-speed motor shift circuit
9
Shuttle valve.
2 position, 3 way EI
Charge pressure circuit that gets
hot oil out of low pressure side of
drive pump and allow slow
pressure flow path for brake
release and 2
-speed motor shift
50 ft-
lbs / 68 Nm
10
Solenoid Valve,
2 position 3 way EJ
Brake release
20 ft-
lbs / 27 Nm
11
Flow
divider/combiner valve EK
Controls flow to non
-steer end
drive motors in forward and
reverse
70 - 75 ft-lbs
95 - 102 Nm
12
Flow divider/combiner valve
EL
Controls flow to steer end drive
motors in forward and reverse
70 - 75 ft-lbs
95 - 102 Nm
13
Or
ifice Plug, 0.090 inch / 2.3 mm EM
Balances flow from flow
divider/combiner (item EA) to
front and rear drive motors
25 ft-
lbs / 34 Nm
14
Diagnostic port
EN
Testing "P1" pressure port
