Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Fuel and Hydraulic Tanks
Part No. 1306587GT GS
™
-84 • GS
™
-90 97
8-1
Fuel Tank
How to Remove the Fuel Tank
Explosion and fire hazard.
Engine fuels ar
e combustible.
Perform this procedure in an
open, well
-ventilated area away
from heaters, sparks, flames and
lighted tobacco. Always have an
approved fire extinguisher within
easy reach.
Explosion and fire hazard. When
transferring fuel, connect a
gr
ounding wire between the
machine and pump or container.
Explosion and fire hazard. Never
drain or store fuel in an open
container due to the possibility of
fire.
1 Turn the key switch to ground controls and
pull out the red Emergency Stop button to the
on position at both ground and platform
controls.
2 Start the engine and raise the platform
approximately 18 feet / 5.5 m from the
ground.
3 Release the safety arm latch, lift the safety
arm and rotate to a vertical position. Lock the
safety arm in position.
Note: Be sure that the safety arm is locked in the
vertical position.
4 Lower the platform onto the safety arm. Turn
the machine off.
Crushing hazard. Keep hands
clear of the safety arm when
lowering the platform.
5 Attach a lifting strap from an overhead crane
to the entry ladder on the hydraulic tank side
of the machine.
6 Remove the entry ladder mounting fasteners.
Remove the entry ladder from the machine.
Crushing hazard. The entry
ladder could become
unbalanced and fall when it is
removed from the machine if it is
not properly supported.
7 Remove the retaining fasteners from the
access plate located behind the hydraulic and
fuel tank tray.
8 Locate and close the 2 fuel tank shutoff
valves located at the fuel tank (if equipped).
9 Tag, disconnect and plug the fuel supply and
return hoses.
10 Remove the fuel filler cap from the tank.
