Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Specifications
Part No. 1306587GT GS
™
-84 • GS
™
-90 7
Oscillate manifold (GS-90) (option)
System relief valve pressure,
maximum
3500 p
si
241 b
ar
Float relief valve pressure
900 p
si
62 b
ar
Oscillate flow regulator
1 g
pm
3.8
L/min
Generator man
ifold (option)
Relief valve
2400 p
si
165.5 b
ar
Flow rate, maximum
4.3 g
pm
16.3 L/min
Welder manifold (option)
Relief valve
270 p
si
18.6 b
ar
Hydraulic motor (welder option)
Displacement
1.28 c
u in
21 c
c
Manifold Component
Specifications
Plug torque
SAE No. 2
36 in-
lbs / 4 Nm
SAE No. 4
10 ft-
lbs / 13 Nm
SAE No. 6
14 ft-
lbs / 19 Nm
SAE No. 8
38 ft-
lbs / 51 Nm
SAE No. 10
41 ft-
lbs / 55 Nm
SAE No. 12
56 ft-
lbs / 76 Nm

Terex Genie GS84D-401 Specifications

General

Brand	Terex
Model	Genie GS84D-401
Category	Lifting Systems
Language	English
