Deutz D 2.9 L4 Engine Fault Codes
132 GS
™
-84 • GS
™
-90 Part No. 1306587GT
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
KWP = Keyword Protocol
SPN
FMI
KWP
Desc
ription
175
2
738
Sensor oil temperature;
plausibility error
175
2
739
Sensor oil temperature;
plausibility error oil temperature
too high
175
3
743
Sensor error oil temperature;
signal range check
high
175
4
744
Sensor error oil temperature;
signal ra
nge check low
190
0
389
Engine speed above warning
threshold (FOC
-Level 1)
190
2
421
Offset angle between crank
- and
camshaft sensor is too large
190
8
419
Sensor camshaft speed;
disturbed
signal
190
8
422
Sensor crankshaft speed;
disturbed signal
190
11
390
Engine speed above warning
threshold (FOC
-Level 2)
190
12
420
Sensor camshaft speed; no
signal
190
12
423
Sensor crankshaft speed; no
signal
190
14
391
Engine speed above
warning
threshold (Overrun Mode)
190
14
1222
Camshaft
- and Crankshaft speed
sensor signal not available on
CAN
411
0
791
Physical range check high for
differential pressure Venturiunit
(EGR)
411
1
792
Physical range check low for
differential pressure V
enturiunit
(EGR)
411
3
795
Sensor error differential pressure
Venturiunit
(EGR); signal range
check high
411
4
381
Physical range check low for
EGR differential pressure
411
4
796
Sensor error differential pressure
Venturiunit (EGR); signal range
check low
SPN
FMI
KWP
Description
412
3
1007
Sensor error EGR cooler
downst
ream temperature; signal
range check high
412
4
1008
Sensor error EGR cooler
downstream temperature; signal
range check low
520
9
306
Timeout Error of
CAN-Receive-
Frame TSC1TR; Setpoint
597
2
49
Break lever mainswitch and
break lever redundancy switch
s
tatus not plausible
624
3
971
SVS lamp; short circuit to batt.
624
4
972
SVS lamp; short circuit to grd.
624
5
969
SVS lamp; open load
624
12
970
SVS lamp; powerstage over
temperature
630
12
376
Access error EEPROM memory
(delete)
630
12
377
Access e
rror EEPROM memory
(read)
630
12
378
Access error EEPROM memory
(write)
639
14
84
CAN
-Bus 0 "BusOff-Status"
651
3
580
Injector 1 (in firing
order); short
circuit
651
4
586
High side to low side short circuit
in the injector 1 (in firing order)
651
5
5
68
Injector 1 (in firing order);
interruption of electric connection
652
3
581
Injector 2 (in firing order); short
circuit
652
4
587
High
side to low side short circuit
in the injector 2 (in firing order)
652
5
569
Injector 2 (in firing order);
interrup
tion of electric connection
653
3
582
Injector 3 (in firing order); short
circuit
653
4
588
High side to low side short circuit
in the
injector 3 (in firing order)
653
5
570
Injector 3 (in firing order);
interruption of electric connection
