Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Electrical Component and Wire Color Legends
Part No. 1306587GT GS
™
-84 • GS
™
-90 161
Item
Description
Y
Valve Coil
Y2
Brake release
Y3
Steer right
Y4
Steer left
Y7
Platform down
Y8
Platform up
Y9
Proportional
control
Y27
Two speed
Y29
Generator on (option)
Y33
Left rear outrigger
Y34
Right rear outrigger
Y35
Left front outr
igger
Y36
Right front outrigger
Y39
Outrigger retract
Y40
Outrigger extend
Y51
Electronic displacement control
Y93
Left
oscillate
Y94
Right oscillate
Y95
Oscillate float
Y100
Oscillate enable
Wire Color Legend
Item
Description
BL
Blue
BK
Bla
ck
BR
Brown
GY
Grey
OR
Orange
PP
Purple
RD
Red
WH
White
YL
Yellow
Wire Color Legend
- Ford Engine
Item
Description
BL
Blue
BK
Black
BR
Brown
DB
Dark Blue
DG
Dark Green
GN
Green
GY
Grey
LB
Light Blue
LG
Light Green
N
Natural
O
Orange
PK
Pink
P
Purple
R
Red
T
Tan
W
White
Y
Yellow
