Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Fault Codes
Part No. 1306587GT GS
™
-84 • GS
™
-90 117
ID
System Ready
LED
Condition
Result
Solution
67
HIGH COOLANT
TEMPERATURE
Red
High coolant temperature.
High engine
temperature OR
defective engine
coolant or oil
temperature switch.
Gasoline/LPG models: Check
the engine
radiator coolant
level OR check the wiring from
the water temperature switch
to ECM OR replace the water
temperature switch.
Diesel models: Check the
engine oil level OR check the
wiring from the oil temperature
switch to ECM OR replace the
oil temperature
switch.
68
LOW ECU
VOLTAGE
Red
Low ECM voltage.
System shutdown.
Charge battery.
69
LOW ENGINE
RPM
Red
Low RPM.
Engine idle RPM too
low.
Contact Genie Product
Support.
70
HIGH ENGINE
RPM
Red
High RPM.
Engine RPM too
high.
Contact Genie Product
Support.
80
L
EFT FRONT
OTRG COIL FLT
Red
Left front outrigger coil (Y35)
fault.
Left front outrigger
function inhibited.
Troubleshoot coil OR wiring.
81
LEFT REAR
OTRG COIL FLT
Red
Left rear outrigger coil (Y33)
fault.
Left front outrigger
function inhibited.
Troubles
hoot coil OR wiring.
82
RIGHT FRONT
OTRG COIL FLT
Red
Right front outrigger coil
(Y36) fault.
Right front outrigger
function inhibited.
Troubleshoot coil OR wiring.
83
RIGHT REAR
OTRG COIL FLT
Red
Right rear outrigger coil
(Y34) fault.
Right rear outrigg
er
function inhibited.
Troubleshoot coil OR wiring.
84
OUTRIGGER
EXT COIL FLT
Red
Outrigger extend coil (Y40)
fault.
Outrigger extend
function disabled.
Troubleshoot coil OR wiring.
85
OUTRIGGER
RET COIL FLT
Red
Outrigger retract coil (Y39)
fault.
Outrig
ger retract
function disabled.
Troubleshoot coil OR wiring.
86
OUTRIGGER
SLOW COIL FLT
Red
Outrigger slowdown coil
(Y44) fault.
Outrigger slow
extend function
disabled.
Troubleshoot coil OR wiring.
90
2
SPEED COIL
FAULT
Red
2
speed coil (Y1) fault
High t
orque drive
function disabled.
Troubleshoot coil OR wiring.
92
DRIVE FWD
PROP COIL
FAULT
Red
Drive pump forward
proportional coil (Y51) fault
Drive forward
function disabled.
Troubleshoot coil OR
wiring.
93
DRIVE REV
PROP COIL
FAULT
Red
Drive pump revers
e
proportional coil (Y51) fault
Drive reverse
function disabled.
Troubleshoot coil OR wiring.
94
MACHINE TYPE
FAULT
Red
Wrong machine type
selected
Machine functions
disabled.
Correct
selection.
102
DOWN LS
CROSS
-CHECK
FLT
Red
Down limit switch fault
All
functions
inhibited except
platform down.
Troubleshoot down limit
switches and wiring.
