Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Fault Codes
Part No. 1306587GT GS
™
-84 • GS
™
-90 119
Error Source
Error Type
Condition
Solution
ID
Name
ID
Name
212
Height sensor
12
Value too high
Output higher than
normal.
• Check wiring
• Check 5V supply voltage
• Shorted too high
• Replace sensor
14
Cross check fault
Height channels not
reading
consistent or
correlated signals
• Check wiring
• Shorted to high or
low
• Replace sensor
15
Value too low
Output lower than
normal.
• Check wiring
• Check 5V supply voltage
• Check ground
• Open or short circuit
• Replace sensor
16
Value at 0 V
Output at
0 volts.
• Check wiring
• Open circuit
• Replace sensor
• Repl
ace SCON
23
Too high
Outputs higher than
calibration point.
• Check height sensor for loose
or missing fasteners.
• Calibrate Sensor
24
Too low
Outputs lower than
calibration point.
• Check height sensor for loose
or missing fasteners
• Calibrate Sen
sor
