Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Deutz TD 2.2 L3 Engine Fault Codes
142 GS
™
-84 • GS
™
-90 Part No. 1306587GT
DTC = Diagnostic Trouble Code
FMI = Failure Mode Identifier
SPN = Suspect Parameter Number
DTC
SPN
FMI
Description
111
102
0
Engine intake manifold pressure
above normal operational range.
1114
102
1
Engine intake manifold pressure
below normal operational range.
1115
102
3
Intake manifold pressure sensor
voltage above normal or shorted t
o
high.
1116
102
4
Intake manifold pressure sensor
voltage below normal or shorted to
low.
1118
102
1
Intake manifold pressure below
normal operational range.
1121
102
2
DFC for signal variation check for
pressure sensor of the intake
manifold.
1122
10
2
0
Intake air pressure valve sensor,
warning condition exceeded.
1123
102
1
Intake air
pressure valve sensor,
shutoff condition exceeded.
1124
1209
2
Engine exhaust pressure turbine
upstream differs from ambient
pressure while engine not running.
1125
1209
15
Engine exhaust pressure turbine
upstream above upper limit.
1126
1176
1
Engine turbocharger compressor
intake pressure below normal
operational range.
1127
1209
2
Engine exhaust pressure turbine
upstream tuck check failed.
Pressure does not chang
e
between engine operating points.
1130
1209
3
Engine exhaust pressure sensor
vo
ltage above normal or shorted to
high.
1131
1209
4
Engine exhaust pressure sensor
voltage below normal or shorted to
low.
DTC
SPN
FMI
Description
1134
3251
3
DPF volta
ge above normal or
shorted to high.
1135
3251
4
DPF voltage below normal or
shorted to low.
1136
3251
14
DPF reporting communication
error.
1137
3251
14
DPF reporting data error.
1138
3251
14
DPF reporting fast channel
1 error.
1139
3251
14
DPF report
ing fast channel 2 signal
range error.
1149
3251
2
DPF difference
pressure value not
plausible.
1150
3251
0
DPF difference pressure above
shut off threshold.
1151
3251
16
DPF difference pressure above
warning threshold.
1152
3251
1
DPF difference press
ure below
shut off threshold.
1153
3251
18
DPF
difference pressure below
warning threshold.
1161
5571
16
Rail fuel pressure relief valve
above normal operational range.
1162
5571
2
Rail fuel pressure relief valve is
forced to open, perform pressure
incr
ease.
1163
5571
2
Rail fuel pressure
relief valve is
forced to open. Performed by
pressure increase.
1164
5571
16
Rail fuel pressure relief valve is
forced to open. Shutoff conditions.
1165
5571
15
Rail fuel pressure relief valve is
forced to open. Warn
ing
conditions.
1166
5571
0
Open
rail fuel pressure relief valve
was detected.
1167
5571
2
Unexpected opening of the rail fuel
pressure relief valve.
1168
5571
2
Successful rail fuel pressure relief
valve opening cannot be ensured.
1169
5571
13
Average
d rail fuel pressure after
valve opening is outside the
expected tolerance range.
