Document 57.0009.0427
37
GTH-4017EX GTH-4514EX GTH-4013EX
November 2008 Section 4 - Maintenance Procedures
TABLE C
C-6 CHECK THE CLAMPING OF THE CABLEHEADS
TO THE BATTERY TERMINALS
Check the cable clips are well secured to the battery
terminals. To tighten the clips, always use a box wrench,
never pliers.
DANGER
- Keep out of items which can produce sparks, of
naked flames or lit cigarettes.
- Do not rest metal objects onto the battery. This
can result in a dangerous short especially during
a recharge.
C-7 CHECK THE AIR SUCTION HOSE BETWEEN
ENGINE AND FILTER
Check the state of all the rubber sleeves A of the air
suction line between engine and filter every month.
CAUTION
If you use the machine continuously for several days,
check these sleeves, as well as the hose clamps
more frequently.
A
A
GTH 4017 EX
GTH 4514 EX
GTH 4013 EX
