Section 2 - Technical Specification November 2008
TECHNICAL SPECIFICATION
Document 57.0009.0427
GTH-4017EX GTH-4514EX GTH-4013EX
2
2.3 LIMIT OF USE
GTH-4017 EX GTH-4514 EX GTH-4013 EX
M1 Obstruction angle ° 37 33 40
M2 Departure angle ° 32 29 46
• Min/max ambient temperature °C -20°/+40° -20°/+40° -20°/+40°
2.4 WEIGHT
TELELIFT 3512 4010
GTH-4017 EX GTH-4514 EX GTH-4013 EX
• Weight with fork Kg 11850 10600 10100
2.5 SPEED
GTH-4017 EX GTH-4514 EX GTH-4013 EX
• Max speed*/** Km/h 5/35 5/35 55/35
• Max slope uphill*/** ° 29/36 31/41 30/34
•
Towing capacity at
dinam. (max load)
kg 8200 8200 7500
•
Towing capacity at
dinam. (with fork)
kg 7250 7250 5835
• Break-out force Kg
7900 (shovel 800It SAE J732/80) 7900 (shovel 800It SAE J732/80) 6000 (shovel 800It SAE J732/80)
• Chassis levelling ° +/- 8 +/- 8 +/-6
TELELIFT 3512 401
2.6 PAYLOAD AND REACH
GTH-4017 EX GTH-4514 EX GTH-4013 EX
• Lifting height (max) with/without outriggers mm 16720/16590 13710/13560 13000/12810
• Forward reach (max) mm 12550 9610 9080
• Reach at maximum height mm 590 560 1900
• Fork-holder plate rotation ° 145 145 138
• Lifting capacity (max) kg 4000 4500 4000
• Lift capacity at maximum height kg 2500 3500 3000
• Lift capacity at maximum reach kg 600 1250 1250
• Floor loading* with/without outriggers kPa 581/581 619/527 469/479
2.2 TYRES
GTH-4017 EX GTH-4514 EX GTH-4013 EX
- Dimension 405/70-24 405/70-20 405/70-20
- Load index 14 pr 14 pr 14 pr
- Rim 13x24 13x20 13x20
- Wheel disc 8 holes DIN 70631 8 holes DIN 70631 8 holes DIN 70631
- Pressure bar/Psi 4.5/65 5.5/80 5.5/80
