CIRCUIT
#
COLOR WIRE
TAG #
FUNCTION CIRCUIT
#
COLOR WIRE
TAG #
FUNCTION
19 YELLOW 011AA FRONT
JACK
PROX.
43 YELLOW 176 SPARE
20 BLUE 013AA FRONT
JACK RET.
44 GRAY 143BK SHIFT COM
21 BLACK 016AB GROUND 45 BLUE 192BA REVERSE
22 BLUE 020AA E-STOP 46 TAN 194BA FORWARD
23 BROWN 021AA E-STOP 47 GREEN 315BA SHIFT LT
24 BLACK 023EA SPARE 48 WHITE 500AA OR
POSITION
49 WHITE 501AA OR
POSITION
COLLECTOR RING-48 CIRCUIT IDENTIFICATION CHART (ROW - EXPORT ENGINE)
CIRCUIT
#
COLOR WIRE
TAG #
FUNCTION CIRCUIT
#
COLOR WIRE
TAG #
FUNCTION
1 RED 0A HOT 25 RED 24 REMOTE
STEER
2 RED 0B HOT 26 YELLOW 25 REMOTE
STEER
3 RED 0C HOT 27 GREEN 26 REMOTE
STEER
4 BLACK 16A GROUND 28 BLUE 55 FUEL
GAUGE
5 WHITE 15 START 29 YELLOW 63 CLEARANC
E LIGHTS
6 RED 17 IGNITION 30 BROWN 64 SPARE
7 BLUE 67 LMI
POWER
31 RED 91 FRONT
O.R.
8 YELLOW 153 CONTROL
POWER
32 GREEN 201 ENGINE
STOP
9 WHITE 1 O.R.
RETRACT
33 BLUE 206 ENGINE
WARNING
10 BLACK
2
2 O.R.
EXTEND
34 BLUE 211 WAIT TO
START
11 RED 3 RIGHT
REAR
JACK
35 BLACK 129 THROTTLE
+5V
493P/N 12261-683 REVISED: January 2015
