11. TEMPERATURE ADJUST-Adjusts heat
temperature.
27. 4 WAY FLASHER-Pull to activate
flashers, push to deactivate.
12. AIR GUAGE (Front)-Indicates air
pressure in front air tank. Maintain 110 to
115 psi normal system air pressure.
28. TRANSMISSION SHIFT LEVER -See
Fuller Manual or Allison Transmission
Operations instructions.
13. PTO AIR VALVE SWITCH-Push up to
engage pumps, push down to disengage.
29. ACCELERATOR PEDAL-Depress to
accelerate.
14. INTER AXLE LOCKOUT VALVE-Lock out
inter-axle differential. Should the machine
become stuck, a spinning wheel will receive
all power transmitted by the drivetrain
causing the wheel to spin faster and worsen
the condition. Use of the lockout divides the
available power between the two axles of
the rear tandem. With the lockout engaged,
the stuck wheel may continue to spin but the
other side of the tandem will begin "driving",
thus
30. BRAKE PEDAL-Depress to actuate.
15. AIR GUAGE (REAR) -indicates air
pressure in rear air tank. Maintain 110 to 115
psi normal system air pressure.
31. CIRCUIT BREAKERS-Electrical circuit
breakers are under this panel.
16. PARKING BRAKE CONTROL VALVE -
Controls parking brakes. Pull to apply, push
to release.
87P/N 12261-683 REVISED: January 2015
