38. LOW AIR PRESSURE-Red colored
Warning Light "ON" if less than 60 PSI.
50. ENGINE COOLANT TEMPERATURE
GUAGE-Guage and Red colored Warning
Light "ON" when engine is at 230 degrees
Farenheit (110 C) or above. Engine is
overheating.
39. DPF TEMPERATURE-Red colored
Warning Light "ON" indicates HIGH exhaust
temperature.
51. LEFT TURN SIGNAL-Green colored
flashing Warning Light "ON".
40. DPF FILTER-Red colored Warning Light
"ON" indicating filter is clogged.
52. TACHOMETER GUAGE-Engine RPM x
100 Guage (0-3500 RPM).
41. WAIT TO START-Red colored Warning
Light "ON". Do not engage starter until light
goes "OFF". (EPA 2010 & Export Engine Only)
53. MENU NAVIGATION BUTTON -LCD
Display screen menu. (See UNIDECK
Operations Instructions).
42. DIFFERENTIAL LOCK-Amber colored
Warning Light "ON". Differential is locked.
54. MIL-MALFUNCTION INDICATOR LIGHT
- The MIL illuminates when the On-Board
Diagnostics system detects a malfunction
related to the emissions control system. The
illuminated MIL indicates that the engine and
aftertreatment system should be diagnosed
and serviced at your next available
opportunity. The MIL can be illuminated
along with any of the engine indicator lamps.
If the MIL is illuminated with the red Stop
Engine Lamp, the vehicle should be stopped
as soon as it is safe to do so. It should be
taken to an authorized Cummins location for
repair.
43. PTO ON-Amber colored Warning Light
"ON", PTO is engaged..
55. OPEN
89P/N 12261-683 REVISED: January 2015
