18
Probe contact procedure for value acquisition
1 Move both measuring head and probe insert
quickly using the rotary power control or the han-
dle 9. You may also enable fast displacement
through the keyboard.
3 Release value capture by means of the rotary
power control or by activating the relevant func-
tion key.
Probe speed:
7,5 mm/s with a resolution to 0,1µm
15 mm/s with a resolution to 1µm
2 Position the insert close to the point to be probed.
The rotary power control must then regain its
neutral position (■).
