TESA Micro-Hite Plus M - Page 46

46
M
Measuring insert
With a 10 mm dia. tungsten carbide cylindrical
face, 12 mm long. Hardened stainless steel body.
ø10
91
Measuring insert
With both a flat and spherical tungsten carbide
measuring face. Hardened stainless steel pin,
interchangeable..
90
95
ø6
R2,5
Insert holder
For increasing the measurement depth.
ø6
75 / 150
69
20
Depth 110 mm (L = 75 mm) N
o
00760086
185 mm (L = 150 mm) N
o
00760087
Insert holder
For extending the application range.
ø6
25
132
20
N
o
00760057
N
o
00760094*
N
o
00760093*
Accessories – Partial set N
o
00760173
Supplied in a molded plastic case* with all
accessories marked with an asterisk «*».
* Not pictured on these pages.
Accessories – Full set N
o
00760148
Supplied in a molded plastic case* with all
accessories listed above.
Special insert holder for TESATAST,
N
o
00760222
Handle for safe transportation of the
height gauge, N
o
00760129.
ø6
73
20
2525
40
