TESA Micro-Hite Plus M - Page 47

47
M
1 Insert holder N
o
00760177
1 Hardened steel pin
For grooves, centring shoulders,
blind bores etc. Tilted through 8°. N
o
00760178
1 Hardened steel pin
For depth measurement. N
o
00760179
3 Measuring inserts
With a tungsten 0,9 mm dia. N
o
00760180
carbide ball tip, 1,9 mm dia. N
o
00760181
hardened. 2,9 mm dia. N
o
00760182
1 Measuring insert
With a 8 mm dia. cone-shaped measuring face
in hardened steel N
o
00760183
2 Extensions
20 mm long for M3 to M3 threads N
o
00760184
20 mm long for M3 to M2,5 threads N
o
00760185
ø4
20
45
ø6
ø4
M3
M3
M3
4,5
8°
8°
78
ø4
8°
3
1,5
0,5
76
ø4
ø1,2
16
26,6
ø0,9
M3
23,1
26,6
ø1,9
M3
22,6
26,6
ø2,9
M3
22,1
28
ø8
M3
25
8
23
ø4
M3
20
M
00760177
0076017900760178
00760180 00760181 00760182 00760183 00760184/5
PROBE INSERT SET
N
o
00760175
Supplied in a suited plastic case.
Insert holder for use with the CAPAX 2000
probe inserts, N° 00760223
67,5
20,7
ø8
00760224
290
ø 75
408
6,35
