Texas Instruments AM335x Sitara User Manual

AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
GEMAC_CPSW
GEMAC_CPSW/MDIO Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
mdio_clk MDIO Clk O R19 M18
mdio_data MDIO Data I/O P17 M17
GEMAC_CPSW/MII1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gmii1_col MII Colision I J19 H16
gmii1_crs MII Carrier Sense I J18 H17
gmii1_rxclk MII Receive Clock I M19 L18
gmii1_rxd0 MII Receive Data bit 0 I P18 M16
gmii1_rxd1 MII Receive Data bit 1 I P19 L15
gmii1_rxd2 MII Receive Data bit 2 I N16 L16
gmii1_rxd3 MII Receive Data bit 3 I N17 L17
gmii1_rxdv MII Receive Data Valid I L19 J17
gmii1_rxer MII Receive Data Error I K19 J15
gmii1_txclk MII Transmit Clock I N19 K18
gmii1_txd0 MII Transmit Data bit 0 O L18 K17
gmii1_txd1 MII Transmit Data bit 1 O M18 K16
gmii1_txd2 MII Transmit Data bit 2 O N18 K15
gmii1_txd3 MII Transmit Data bit 3 O M17 J18
gmii1_txen MII Transmit Enable O K17 J16
GEMAC_CPSW/MII2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gmii2_col MII Colision I V18 U18
gmii2_crs MII Carrier Sense I R15 T17
gmii2_rxclk MII Receive Clock I NA T15
gmii2_rxd0 MII Receive Data bit 0 I NA V17
gmii2_rxd1 MII Receive Data bit 1 I NA T16
gmii2_rxd2 MII Receive Data bit 2 I NA U16
gmii2_rxd3 MII Receive Data bit 3 I NA V16
gmii2_rxdv MII Receive Data Valid I NA V14
gmii2_rxer MII Receive Data Error I W18 U17
gmii2_txclk MII Transmit Clock I NA U15
gmii2_txd0 MII Transmit Data bit 0 O NA V15
gmii2_txd1 MII Transmit Data bit 1 O NA R14
gmii2_txd2 MII Transmit Data bit 2 O NA T14
gmii2_txd3 MII Transmit Data bit 3 O NA U14
gmii2_txen MII Transmit Enable O NA R13
GEMAC_CPSW/RGMII1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
rgmii1_rclk RGMII Receive Clock I M19 L18
rgmii1_rctl RGMII Receive Control I L19 J17
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 71
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
