AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
GEMAC_CPSW/RGMII1 Signals Description (continued)
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
rgmii1_rd0 RGMII Receive Data bit 0 I P18 M16
rgmii1_rd1 RGMII Receive Data bit 1 I P19 L15
rgmii1_rd2 RGMII Receive Data bit 2 I N16 L16
rgmii1_rd3 RGMII Receive Data bit 3 I N17 L17
rgmii1_tclk RGMII Transmit Clock O N19 K18
rgmii1_tctl RGMII Transmit Control O K17 J16
rgmii1_td0 RGMII Transmit Data bit 0 O L18 K17
rgmii1_td1 RGMII Transmit Data bit 1 O M18 K16
rgmii1_td2 RGMII Transmit Data bit 2 O N18 K15
rgmii1_td3 RGMII Transmit Data bit 3 O M17 J18
GEMAC_CPSW/RGMII2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
rgmii2_rclk RGMII Receive Clock I NA T15
rgmii2_rctl RGMII Receive Control I NA V14
rgmii2_rd0 RGMII Receive Data bit 0 I NA V17
rgmii2_rd1 RGMII Receive Data bit 1 I NA T16
rgmii2_rd2 RGMII Receive Data bit 2 I NA U16
rgmii2_rd3 RGMII Receive Data bit 3 I NA V16
rgmii2_tclk RGMII Transmit Clock O NA U15
rgmii2_tctl RGMII Transmit Control O NA R13
rgmii2_td0 RGMII Transmit Data bit 0 O NA V15
rgmii2_td1 RGMII Transmit Data bit 1 O NA R14
rgmii2_td2 RGMII Transmit Data bit 2 O NA T14
rgmii2_td3 RGMII Transmit Data bit 3 O NA U14
GEMAC_CPSW/RMII1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
rmii1_crs_dv RMII Carrier Sense / Data Valid I J18 H17
rmii1_refclk RMII Reference Clock I/O K18 H18
rmii1_rxd0 RMII Receive Data bit 0 I P18 M16
rmii1_rxd1 RMII Receive Data bit 1 I P19 L15
rmii1_rxer RMII Receive Data Error I K19 J15
rmii1_txd0 RMII Transmit Data bit 0 O L18 K17
rmii1_txd1 RMII Transmit Data bit 1 O M18 K16
rmii1_txen RMII Transmit Enable O K17 J16
GEMAC_CPSW/RMII2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
rmii2_crs_dv RMII Carrier Sense / Data Valid I R15, U17 T13, T17
rmii2_refclk RMII Reference Clock I/O J19 H16
rmii2_rxd0 RMII Receive Data bit 0 I NA V17
rmii2_rxd1 RMII Receive Data bit 1 I NA T16
rmii2_rxer RMII Receive Data Error I W18 U17
rmii2_txd0 RMII Transmit Data bit 0 O NA V15
72 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
