375
/* Disable USCI */
UCA0CTL1 |= UCSWRST;
/*
* Control Register 0
*
* ~UCPEN -- Parity Disabled
* UCPAR -- Even parity
* ~UCMSB -- LSB first
* ~UC7BIT -- 8-bit
* ~UCSPB -- One stop bit
* UCMODE_0 -- UART Mode
* ~UCSYNC -- Asynchronous mode
*
* Note: ~<BIT> indicates that <BIT> has value zero
*/
UCA0CTL0 = UCPAR | UCMODE_0;
/*
* Control Register 1
*
* UCSSEL_2 -- SMCLK
* ~UCRXEIE -- Erroneous characters rejected and UCAxRXIFG is not set
* ~UCBRKIE -- Received break characters do not set UCAxRXIFG
* ~UCDORM -- Not dormant. All received characters will set UCAxRXIFG
* ~UCTXADDR -- Next frame transmitted is data
* ~UCTXBRK -- Next frame transmitted is not a break
