18 Performing an Experiment
The Keep current reading icon becomes active. The sensor shows
the data point in the center of the screen.
5. Click Experiment > Keep for each data point you want to keep.
The Events with Entry dialog box opens.
6. Type the value of the data point.
7. Click OK.
The data point is saved in the appropriate location on the graph. The
next point appears in the center of the graph.
8. Repeat steps four, five, and six until you collect all of the desired data
points.
9. Click
Experiment > Stop Collection.
The data set run is complete.
Collecting Data in the Events with Entry Mode Average
over 10 Option
Use this procedure only after you assign Events with Entry as the
collection mode and select the option Average over 10 option.
To collect data using the Events with Entry mode Average over 10 s
option:
1. Click
Experiment > New Experiment to reset the sensor to its default
values.
This step removes any existing data and ensures the connected sensor
is set to its default values.
2. Connect a sensor.
Note: When you connect a sensor, the sensor name is added to the
sensor list.
3. Assign the Events with Entry mode Average over 10 s option.
4. Click
Experiment > Start Collection.
