THRUSH AIRCRAFT, INC – MODEL S2R-G10
AIRCRAFT MAINTENANCE MANUAL
Effective: 03/26/2010 page 1-3
HORIZONTAL STABILIZER AND ELEVATORS
Span............................................... 204 Inches (17')
Elevator Travel
Up........................................ 27 Degrees ±1 Degree
Down ................................... 17 Degrees ±1 Degree
Trim Tab Travel
Up........................................ 8 Degrees ±1 Degree
Down ................................... 22 Degrees ±1 Degree
VERTICAL STABILIZER AND RUDDER
Vertical Fin Offset........................... 0 Degrees ±1 Degree Left and Right
Rudder Travel ................................ 19 Degrees ±1 Degree Left and Right
AREAS
Wing............................................... 356.3 Square Feet
Aileron (Each)................................. 23.4 Square Feet
Flaps (Each)................................... 15.3 Square Feet
Stabilizer......................................... 39.3 Square Feet
Elevators ........................................ 20.4 Square Feet
Elevator Tabs (Each)...................... 1.3 Square Feet
Vertical Fin .................................... 9.4 Square Feet
Rudder ........................................... 12.2 Square Feet
SUPPLIER FURNISHED COMPONENT MANUALS
COMPONENT MANUAL PART #
TPE331-G10 Maintenance Manual 72-00-27
TPE331-G10 Parts Manual 72-01-16
Propeller Owner’s Manual N/A
Note: Should there be a conflict between the information in this manual and that in the
manuals for component parts, the information in the component part manual takes
precedence.
