TD80™ Level Gauging and Overfill Prevention System Product Manual
Page 154 TD80 Programming/ Rev. 2, August 4, 2015
Text File Interpretation
Information from line 1 indicates the date this file was created or last modified.
Lines 2 to 6 provide information to Birdfeeder 2 for Volume Units, Depth Units, High-High
Level, Display Precision and Spill Alarm Level.
The example above indicates:
1. The programming file was created on 23 November, 2006 at 8:42 am.
2. The transmitter is programmed to display barrels (BBL).
3. The depth units used for the chart is inches (in).
4. The High-High (HH) alarm is programmed for 231.0 BBL (see line 7 above) at a
depth of 78”
5. The Finch display is set for one decimal place of precision.
6. The Spill alarm is set at a distance of 8” from the tank top or a depth of 79” (see line 8
above) and a volume of 232.2 BBL. The actual Spill level is 7.5” or 79.5” and a
volume of 232.75 BBL. Spill Level=8 is an indication that this table was created for a
dual rod transmitter. Any other Spill Alarm level of 2.5” to 15.5” indicates a coaxial
transmitter.
Additional information is needed to complete the programming in Birdfeeder 2. Customer
records are required to determine the coaxial transmitter Spill Alarm Reset. The most
common setting is Auto-Clear. Mechanical details such as riser or sump installation may
be required to convert to a Birdfeeder 2 formatted file (.STB). These details and the
optional 4-20mA settings may be supplied by the customer.
MDU Format Text File Conversion
The following steps describe how to convert an MDU formatted text file for use with
Birdfeeder 2. A typical installation is with a dual rod probe, no sump or riser to
compensate for the top and bottom dead bands and no 4-20mA option installed.
1. Run the Birdfeeder 2 program.
2. At the Menu Bar, click File>Import Table…
3. Select the text file for conversion and click the Open button
4. Confirm the following settings and correct as necessary. All required settings are
determined by the text file header.
a. Probe Type
b. Depth Units
c. Volume Units
d. Spill Alarm Level
e. Optional Spill Alarm Reset
f. HH level
g. Display precision
5. Ensure that sump and riser height is 0”.
6. Ensure that the 4mA and 20mA set points are 0” or at the customer specified
settings.
7. Click on the Verify icon to scan the chart for errors. Correct any identified errors and
continue.
8. Save the newly created file by clicking on the Save icon and following the prompts.
The new file is saved with the .STB extension to indicate it is a Birdfeeder 2 format.
