TD80™ Level Gauging and Overfill Prevention System Product Manual
Page 162 TD80 Programming/ Rev. 2, August 4, 2015
TPM 001
6.3.8 Programming Checklist
Checked
Step
1. Gather all the programming information
a. Transmitter and probe type
b. Depth chart for the tank or compartment
c. Display precision required for the Finch display
d. Transmitter riser and sump options
e. Spill alarm distance
f. Spill alarm reset option
g. High-High alarm volume
h. Optional 4-20mA offset adjustments
2. Create the programming file, if required
a. Confirm all settings with the information above
b. Save the file with a meaningful name
3. Program the TD80
a. Verify all programming settings with the information above.
b. Program the TD80
4. Test the programming result
a. TD80 operates normally
b. Volume is displayed according to the depth chart
c. Alarms activate at the programmed levels
d. Optional Spill alarm reset clears the alarm
e. Optional 4-20mA outputs according to programmed offsets
Table 6-1: Programming Checklist
