2 Document Ref 942583-001 Rev 8
Revision Record Quantium 510 Installation Manual
Date Revision Chapter Reason
31/03/2011 5 All Added Tokheim graphic to bottom of page.
5 3.2.1 to 3.2.5,
3.2.7 & 3.2.10
Added the dimension 58, edge of driptray to mounting hole, to
drawings.
5 3.2.9 Change of dimension, driptray to mounting hole from 918.5 to
922.5
5 5.2 Photographs to identitify side a & side b
08/07/2011
3 (Rev 5.1) 3.1.11 Added gound frame prt.no. 3.2.11 update to Mini Sat
drawing (Bottom view)
6 (Rev 5.1) Up rev to 5.1 to include new instructions 6.1.3 on flow rate set
up of VR.
22/12/2011 3 (Rev 5.1) 3.2.11 Update to Mini Sat drawing (Top view)
23/01/2012 6 All
6 1.5.3 Additional text to highlight care and attention when removing
and storing lighter panels and cladding.
6 1.6 Addition of the Stage II Vapour Recovery system European
Directive
08/03/2012 6.1 1.7 Change to text (Meter Calibration)
6 2.2.3 Addition of models SVHS 3-4 & SVHS 4-6
6 2.3.3 Update to all VR drawings
6 3.1.3 Addition of text to SVHS 3-4
6 3.1.6 Addition of text to SVHS 4-6
6 3.1.10 Addition of groundframe table
6 3.1.12 Updated drawing and changed name Display Heights to
Dispenser Heights.
6 3.2.3 Addition of text to SVHS 3-4
6 3.2.6 Addition of text to SVHS 4-6
6 5.4.5 Placement procedures for M-SAT dispenser with lifting slots.
08/03/2012 6.1 6.2 Change to text (MID certified dispensers)
6 Front Cover Change to front cover
6 Back Cover Change to back cover
27/07/2012 6.1 2.3 Change to Note - Tokheim requires rigid pipes for SAT lines
6.1 5.4.1 New photograph Item 10
6.1 5.4.2 New photograph Item 9
6.1 5.4.3 New information. Addition of forklift pitch chart & new dispenser
photos.
6.1 5.4.4 New photographs, Item 5 & Item 10
6.1 5.4.5 New photographs, Item 4 & Item 9
6.1 5.4.7 New information. Addition of Using jacking bolts to lower a
dispenser.
6.1 5.5.1 New photographs for suction dispensers pipework.
6.1 6.3 Important info on removing transport bolts
6.2 New revision record
06/09/2012 6.3 P2 Revision Record updated
6.2 P2-29 Section added for VR per Product (Ethanol Split Only)
6.1 P3-15 to 3-23 VR Per Product (Ethanol Split Only) note added to drawings
6.1 P3-25 Mini Sat Ground Plan updated
6.2 P5-28 to 5-31 Drawing updates
07/03/2013 7 3,4,5 Main Contents updated
2-20 Changes to Note
3-1 Section 3 Contents updated
