2-2
2.1 EXAMINER'S SIDE
) HAND REST
The Hand Rest is used to place the hand while it is used to turn the Joystick. The Hand Rest
is also used for roughly adjusting the Measurement Head front/rear/left/right. (See Section
2.4.)
* PRINTER
Prints measurement results.
+ EYE LEVEL MARK
The level of the patient's eye to be measured is adjusted to this mark.
, RS232C CONNECTOR
This Connector terminal is used to connect external equipment to this instrument. (See "2.6
RS-232C CONNECTOR".)
- SERVICE MODE SELECT SWITCH
This Select Switch is used for version-up of the software.
. CLEAR BUTTON
Measurement data are deleted with this button.
/ MODE BUTTON
The measurement mode is selected.
0 PRINT BUTTON
Starts the printing.
1 AUTO BUTTON
Changes over Auto Measurement or Manual measurement.
2 IOL/CAT BUTTON
When Refractive measurement, the IOL mode or the CAT mode is changed over.
3 DATA Link BUTTON
Sends out the measured data into a computer etc.
4 PACKING BUTTON
The Measurement Head is moved to a place which is appropriate for packing.
5 CHIN REST BUTTON
The Chin Rest rises by pressing the "S" Button and lowers by pressing the "T" button.
6 POWER LAMP
The Power Lamp lights up while the Power is on.
To Next Page
