Tomey RC-5000 User Manual

2-3
2.2 PATIENT'S SIDE
$ MEASUREMENT WINDOW
The Patient looks at the fixation target through the Measurement Window.
% CHIN REST
Patient's chin is placed on the Chin Rest.
& HEAD REST
Patient's forehead is placed to the Head Rest.
' POWER SWITCH
The power is turned on by pressing the side of " I (ON)" and turned off by pressing the side
of " O (OFF)".
( POWER CONNECTOR
The power cable is connected to the Power Connector.
) FUSE HOLDER
The fuse is placed in the Fuse Holder.
* FIXATION TARGET
Fixation target is in the measurement window. Leading Patient's eye fixation.
Ԙ
ԙ
Ԛ
ԛ
Ԝ
ԝ
Ԟ
2.2 PATIENT'S SIDE
