Tomey RC-5000 User Manual

2-6
4 TARGET LUMINOUS SPOT
The corneal vertex position of the eye to be examined is indicated.
5 TARGET RING
The indicator for positioning the eye to be examined when measurement.
6 MINIMUM PUPILLARY DIAMETER RING
The measurable minimum pupil diameter is indicated.
7 AUTO ALIGNMENT RING
The effective range of auto alignment is displayed.
FOCUS INDICATOR
The distance between the Measurement Head and the eye to be examined is indicated.
When the bar appears left and right, the Joystick is tilted forward, and when the bar appears
up/down, the Joystick is tilted toward your side, for focusing.
AUTO SHOT MARK
The Auto Shot Mark is displayed in the effective time of auto shot.
AUTO ALIGNMENT MARK
The Auto Alignment Mark is displayed in the effective time of auto alignment.
IOL/CAT MODE DISPLAY
The IOL mode displays an IOL picture, CAT mode displays a crystalline lens picture.
HEAD BACKUP BUTTON
The head backs up toward the operator.
2.3 MEASUREMENT SCREEN
