GUIDANCE AND MANUFACTURER'S DECLARATION
ON ELECTROMAGNETIC IMMUNITY
The RC-5000 is intended for use in the following electromagnetic environments. The customers
and the user of the RC-5000 is advised to guarantee the following environments.
Immunity test IEC 60601 Test
level
Compatibility
level
Electromagnetic environments-
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 6kV contact
± 8kV air
± 6kV contact
± 8kV air
Wooden, concrete, or ceramic flooring
material is preferable. If synthetic
materials are used, a relative humidity
of at least 30% is preferable.
Electrically high
speed transient
phenomena/burst
IEC 61000-4-4
± 2kV for power
source cord
± 1kV for input &
output cords
± 2kV for power
cord
± 1kV for input &
output cords
As for the power source quality,
typically commercial or hospital
purpose quality is preferable.
Surge
IEC 61000-4-5
± 1kV
differential mode
± 2kV
common mode
± 1kV
differential mode
± 2kV
common mode
As for the power source quality, the
typically commercial or hospital
purpose quality is preferable.
Voltage dip,
instantaneous
stop, and power
voltage fluctua-
tion with power
input cord
IEC 61000-4-11
<5 % UT
(at >95 % dip UT)
for 0,5 cycle
40 % UT
(at 60 % dip UT)
for 5 cycles
70 % UT
(at 30 % dip UT)
for 25 cycles
<5 % UT
(at >95 % dip UT)
for 5 sec.
<5 % UT
(at >95 % dip UT)
for 0,5 cycles
40 % UT
(at 60 % dip UT)
for 5 cycles
70 % UT
(at 30% dip UT)
for 25 cycles
<5 % UT
(at>95% dip UT)
for 5 sec.
The electric power quality for typical
commercial use or hospital environ-
ment is preferable. If the user of the
RC-5000 requires continuous opera-
tion at the time of power suspension,
the RC-5000 is recommended to be
powered by interruptible power
source.
Electric power
frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m The electric power frequency magnetic
field is preferably rated at the level
equivalent to that for typical commer-
cial or hospital environments.
Remarks: "UT" is the AC mains voltage prior to application of the test level.
