3-4
● Connecting LAN cables
Prepare the following items.
- LAN cables (straight type, category 5 or higher) : 2
- A network hub (A 100MHz switching hub recommended) : 1
- A computer with TOMEY Link or DATA Transfer installed : 1
i) Connecting of the power plug of the Fixation Lamp for Chin Rest
1) The Fixation Lamp is interlocked with the ON/OFF power
source for the instrument.
2) Insert the Power plug (1) for Chinrest fixation lamp into the
terminal marked with “FIX LIGHT” provided at the rear
side of the main unit.
To Next Page
