3-21
■
j) Full screen display
This function zooms the measurement data to the maximum size on the screen.
■
The zoom function is not available while the full screen function is
activated. Return to the measurement screen to edit the data.
1) Touch the “FullSize" button (1) to open the Full Size screen.
2) Select a tab to display a measurement tool (length, angle, or area).
3) Touch the “Back" button (2) to return to the measurement screen.
● IOL eye (acryl)
Select this when there is an acrylic IOL implant.
● User Setting
Select this when registering optional materials for IOL eyes.
Register the settings on the converted acoustic velocity setting screen. (Refer to “3.3.1 b)
Setting converted acoustic velocity.”)
“Anterior chamber depth” and “lens” are not measured for an aphakic eye and “lens” is
not measured for an IOL eye.
The instrument may not recognize waveforms on the back of the crystal lens due to
multiple echoes in the crystal lens in an eye with dense cataracts.
ACD (anterior
chamber depth)
Phakic eye (Average acoustic
velocity, divisional acoustic velocity)
