19-10
19 TOP FIELD MODE
Setting by entering the coordinate data of a collimate point directly
Operating procedure Operation Display
After the occupied point setting is completed,
this menu will be displayed.
1 Select {F2} (CREATE BS PT).
{F2}
2 Select {F1} (INPUT PT).
{F1}
3 Enter the coordinate point of a collimate point and
its description.
Enter PT #,
Enter
DESC
4 Set with {ENT} key.
{ENT}
5 Enter collimate point coordinates (N, E, Z).
Enter colli-
mate point
coordiante
6 Set with {ENT} key.
{ENT}
7 Enter a reflector height.
Enter
reflector
height
8 Set with {ENT} key.
{ENT}
9 From here to the backsight setting, follow the
same procedure to set backsight from existing
coordinate data.
1.SELECT BS PT
2.CREATE BS PT
3.BS DIRECTION
[1] [2] [3]
1.INPUT PT
2.MEAS PT
[1] [2]
ENTER NEW POINT:
PT#: [_ ]
DESC: [ ]
ALP CLR
ENTER NEW POINT:
PT#: [BS ]
DESC: [POINT_ ]
ALP CLR
N [ ]
E [ ]
Z [ ]
ALP CLR
N [10.000 ]
E [10.000 ]
Z [0.000 ]
ALP CLR
ENTER BS HEIGHT
BS HT
=0.000_ m
CLR
ENTER BS HEIGHT
BS HT
=1.500_ m
CLR
SIGHT BS TARGET
1.MEAS ANG+DIST
2.MEAS ANG ONLY
