3 ANGLE MEASUREMENT
3.5 Repetition Angle Measurement

• Repetition angle measurement can be done by horizontal angle right measurement mode.
Make sure the mode is Horizontal Angle Right measurement.
Operating procedure Operation Display
1 Press the {F4} ( ↓ ) key to get the function on page
2.
{F4}
2 Press the {F2} (REP)key.
{F2}
3 Press the {F3} (YES) key.
{F3}
4 Collimate the target A and press the {F1} (0SET)
key.
Collimate A
{F1}
5 Press the {F3} (YES) key.
{F3}
6 Collimate the target B using the horizontal clamp
and tangent screw.
Press the {F4} (HOLD) key.
Collimate B
{F4}
7 Recollimate target A using the horizontal clamp
and tangent screw, and press the {F3} (REL)key.
Collimate A
{F3}
8 Recollimate target B using the horizontal clamp
and tangent screw, and press the {F4} (HOLD)
key.
Collimate B
{F4}
9 Repeat 7 to 8 to measure the desired number of
repetitions.
[Example] 4 measurement
V : 90°10'20"
HR: 170°30'20"
0SET HOLD HSET P1
↓
TILT REP V% P2 ↓
REPETITION ANGLE
>OK?
--- --- [YES][NO]
REP-ANGLE COUNT[ 0]
Ht: 0°00'00"
Hm:
0SET V/H REL HOLD
REPETITION ANGLE
INITIALIZE
>OK?
--- --- [YES][NO]
REP-ANGLE COUNT[ 0]
Ht: 0°00'00"
Hm:
0SET V/H REL HOLD
REP-ANGLE COUNT[ 1]
Ht: 45°10'00"
Hm: 45°10'00"
0SET V/H REL HOLD
REP-ANGLE COUNT[ 1]
Ht: 45°10'00"
Hm: 45°10'00"
0SET V/H REL HOLD
REP-ANGLE COUNT[ 2]
Ht: 90°20'00"
Hm: 45°10'00"
0SET V/H REL HOLD
REP-ANGLE COUNT[ 4]
Ht: 180°40'00"
Hm: 45°10'00"
0SET V/H REL HOLD
