Topcon ES-65 - Go to Work; To Set Occupied Point and Backsight

19-4
19 TOP FIELD MODE
19.4 GO TO WORK
The following operations are performed with GO TO WORK.
1) Setting of occupied point and backsight ••••••INST SETUP
2) Layout ••••••LAYOUT
3) Ordinary measuring and coordinate saving ••••••TOPO
19.4.1To Set Occupied Point and Backsight
To set occupied point
 Selecting from existing coordinate data
4 Select {F1} to {F3} to set the unit of distance.
{F1} (US FEET-10THE): Display in feet
{F2} (US FEET-INCHES): Display in feet and
inches
{F3} (METERS): Display in meters
Select
{F1} ~ {F3}
5 Select {F1} to {F3} to set the display sequence of
coordinates.
{F1} (N,E,Z): Display N, E, Z
{F2} (E,N,Z): Display E, N, Z
{F3} (X,Y,Z): Display X, Y, Z
Select
{F1} ~ {F3}
6 Select {F1} ~ {F3} to set the distance
measurement mode.
{F1} (FINE): FINE mode
{F2} (CRS-1mm): COARSE mode (Rounding in
the unit of 1mm)
{F3} (CRS-10mm): COARSE mode (Rounding in
the unit of 10mm)
Select
{F1} ~ {F3}
7 Press {F1} (OK) to set.
{F1}
Operating procedure Operation Display
1 Select {F1} (INST SETUP).
{F1}
1.N,E,Z
2.E,N,Z
3.X,Y,Z
[1] [2] [3]
1.FINE
2.CRS-1mm
3.CRS-10mm
[1] [2] [3]
DIST UNITS :METERS
COORDINATES :NEZ
EDM MODE :CRS-10
OK EDIT
1.JOB [ ]
2.SETTING
3.GO TO WORK
[1] [2] [3]
↓
1.JOB [JOB1 ]
2.SETTING
3.GO TO WORK
[1] [2] [3]
↓
1.INST SETUP
2.LAYOUT
3.TOPO
[1] [2] [3]
{F3}
1.INST SETUP
2.LAYOUT
3.TOPO
[1] [2] [3]
1.SELECT INST PT
2.CREATE INST PT
3.MEAS KNWN PTS
[1] [2] [3]
