6 SPECIAL MODE (Menu Mode)
6 SPECIAL MODE (Menu Mode)
By pressing the {MENU} key, the instrument will be in MENU mode.
In this mode, special measuring, setting and adjustment are possible.
"DATA COLLECTION MODE"
Normal measurement mode
"LAYOUT MODE"
"MEMORY MANAGER MODE"
MENU 1/4
F1:TOP FIELD
F2:DATA COLLECT
F3:LAYOUT P
↓
MENU 2/4
F1:MEMORY MGR.
F2:PROGRAMS
F3:GRID FACTOR P
↓
MENU 3/4
F1:ILLUMINATION
F2:PARAMETERS 1
F3:PARAMETERS 2 P
↓
See Chapter 7 “DATA COLLECTION”.
See Chapter 8 “LAYOUT”.
See Chapter 9 “MEMORY
MANAGER MODE”.
{F1}
{F2}
{F3}
PROGRAMS 1/2
F1:REM
F2:MLM
F3:Z COORD. P
↓
GRID FACTOR
=1.000000
>MODIFY?[YES][NO]
ILLUMINATION[ON:1]
F1:ON
F2:OFF
F3:LEVEL
CONTRAST ADJUSTMENT
LEVEL:4
↓ ↑ --- ENTER
{ESC}
{ESC}
{ESC}
{ESC}
{F4
{MENU}
{F4
{ESC} {F1}
{F2}
{F3}
{ESC}
{F4
{ESC}
Programs
Grid factor
Reticle illumination
Display contrast adjustment
{F1}
{F2}
{F3}
"TOP FIELD MODE"
See Chapter 19 “TOP FIELD MODE”.
MENU 4/4
F1:ADJUSTMENT MODE
F2:CONTRAST ADJ.
P
↓
"SETTING MODE 1"
See Section 6.4 “Setting Mode 1”.
"SETTING MODE 2"
See Chapter 9 “MEMORY
MANAGER MODE”.
"ADJUSTMENT MODE"
See Chapter 18 “CHECKS AND
ADJUSTMENTS”.
{ESC}
{F1}
{F2}
