Topcon ES-65 - Preparation; Selecting a File for Data Collection

7-3
7 DATA COLLECTION
7.1 Preparation
7.1.1 Selecting a File for Data Collection
A file used by data collection mode must be selected at first.
Select a file before beginning data collection mode because selection screen of a file is displayed. And
a selection from data collection menu is possible in the mode.
Operating procedure Operation Display
1 Press {F2} (DATA COLLECT) key from menu 1/3.
{F2}
2 Press {F2} (LIST) key to display the list of file. *1)
{F2}
3 Scroll file list by pressing {} or { } key and
select a file to use. *2),3)
{} or {}
4 Press {F4} (ENTER) key.
The file will be set and data collect 1/2 menu will
be shown.
{F4}
*1) If you want to make a new file or input file name directly, press {F1} (INPUT) key and enter a file name.
*2) When a file has been selected already, '*' mark is indicated on left of current file name.
*3) Data in a file shown with arrow can be searched by pressing {F2} (SRCH) key.

• It is possible to select a file from DATA COLLECT 2/2 menu in the
same way.
MENU 1/3
F1:TOP FIELD
F2:DATA COLLECT
F3:LAYOUT P
↓
SELECT A FILE
FN:_________
INPUT LIST ––– ENTER
AMIDATA /M0123
→ *HILDATA /M0345
TOPDATA /M0789
––– SRCH ––– ENTER
TOPDATA /M0789
→ RAPDATA /M0564
SATDATA /M0456
––– SRCH ––– ENTER
DATA COLLECT 1/2
F1:OCC.PT# INPUT
F2:BACKSIGHT
F3:FS/SS P
↓
DATA COLLECT 2/2
F1:SELECT A FILE
F2:PCODE INPUT
F3:CONFIG. P
↓
