Topcon ES-65 - Set OCC and BS

6-33
6 SPECIAL MODE (Menu Mode)
6.6.5 Set OCC and BS
To set the Occupied Point and Backsight Point, carry out the following operating procedure.
Operating procedure Operation Display
1 After pressing the {MENU} key, press the {F4} (P ↓ ),
{F2} , {F4} key to get the programs menu on page 2/
2.
{MENU}
{F4}
{F2}
{F4}
2 Press the {F3}, {F2}, {F1} key.
(
Refer to “Set OCC and BS” on page 6-26.)
{F3}
{F2}
{F1}
3 Press the {F1} key. *1)
{F1}
4 To input OCC. PT, press
the {F1} (COORD. DATA) or {F2} (ROAD DATA)
key.
COORD. DATA:
Choose the data from Coord Data and set the
Occupied Point.
ROAD DATA:
Create the data from Road Data and set the
Occupied Point.
(Example: ROAD DATA)
{F2}
5 Input OCC. PT, press the {ENT} key.
Input
OCC. PT
{ENT}
6 Press the {ENT} key.
LEFT or RIGHT: Use the offset point.
CENTER: Use the center point.
(Example: CENTER)
{ENT}
7 Press the {F3} (YES) key.
{F3}
8 Input the backsight.
9 Press the {ENT} key.
Input
Backsight
{ENT}
PROGRAMS 2/2
F1:AREA
F2:POINT TO LINE
F3:ROAD P↓
OCC&BS
F1:OCC&BS
F2:RESECTION
OCC&BS
F1:COORD. DATA
F2:ROAD DATA
OCC.PT
CHAIN=
--- --- [CLR] [ENT]
CHAIN:1000.000
>CENTER
LEFT RIGHT --- ENTER
CHAIN:1000.000
N : 0.000 m
E : 0.000 m
>OK ? [YES][NO]
BACKSIGHT
CHAIN=
--- --- [CLR] [ENT]
CHAIN: 0.000
>CENTER
LEFT RIGHT --- ENTER
