Topcon ES-65 - Data Manager; To Add Coordinate Data to Add Coordinate Data

19-16
19 TOP FIELD MODE
19.5 DATA MANAGER
The following operations can be performed with DATA MANAGER.
1) Adding coordinate data ••••••ADD POINT
2) Deleting coordinate data ••••••DELETE POINT
3) Viewing coordinate data ••••••VIEW POINT
4) Editing coordinate data ••••••EDIT POINT
5) Transferring coordinate data ••••••DATA TRANSFER
19.5.1To Add Coordinate Data To Add Coordinate Data
 Entering coordinates directly (COORDINATES)
Operating procedure Operation Display
Select {F1} (ADD POINT).
Coordinates can be added through the following
procedure:
1. COORDINATES
2. REFLINE
3. TAPE
{F1}
Operating procedure Operation Display
1 Select {F1} (COORDINATES).
{F1}
2 Enter a coordinate point and its description.
Enter PT#,
Enter
DESC
3 Set with {ENT} key.
{ENT}
4.DATA MANAGER
[4]
↑
1.ADD POINT
2.DELETE POINT
3.VIEW POINT
[1] [2] [3]
↓
4.EDIT POINT
5.DATA TRANSFER
[4] [5]
↑
{F1}
{F4}
1.ADD POINT
2.DELETE POINT
3.VIEW POINT
[1] [2] [3]
↓
1.COORDINATES
2.REFLINE
3.TAPE
[1] [2] [3]
1.COORDINATES
2.REFLINE
3.TAPE
[1] [2] [3]
ENTER NEW POINT:
PT#: [_ ]
DESC: [ ]
ALP CLR
ENTER NEW POINT:
PT#: [P01 ]
DESC: [POINT_ ]
ALP CLR
N [_ ]
E [ ]
Z [ ]
CLR
