3 ANGLE MEASUREMENT
3.3.2 Setting a Horizontal Angle from the Keys
Make sure the mode is Angle measurement.
3.4 Vertical Angle Percent Grade(%) Mode
Make sure the mode is Angle measurement.
Operating procedure Operation Display
1 Collimate the target.
Collimate
2 Press the {F3} (HSET) key.
{F3}
3 Input the required horizontal angle by
using keys. *1)
For example:70°40'20"
When completed, normal measuring from the
required Horizontal angle is possible.
70.4020
{F4}
*1) To enter Alphanumeric characters, see Section 2.4 “How to Enter Alphanumeric Characters”.
Operating procedure Operation Display
1 Press the {F4} ( ↓ ) key to get the function on page
2.
{F4}
2 Press the {F3} (V%) key. *1)
{F3}
*1) Every time pressing the {F3} (V%) key, the display mode switches.
 When the measurement is carried out over ±45° (±100%) from the horizontal, the display shows
<OVER>.
V : 90°10'20"
HR: 170°30'20"
0SET HOLD HSET P1
↓
H ANGLE SET
HR=
--- --- [CLR] [ENT]
V : 90°10'20"
HR: 70°40'20"
0SET HOLD HSET P1
↓
V : 90°10'20"
HR: 70°40'20"
0SET HOLD HSET P1
↓
TILT REP V% P2 ↓
V : -0.30 %
HR: 170°30'20"
TILT REP V% P2
↓
