19-5
19 TOP FIELD MODE
 Setting by entering the coordinate data of a occupied point directly
2 Select {F1} (SELECT INST PT).
{F1}
3 Select an existing coordinate point with {F1} or
{F2} (Arrow) key, or directly enter a coordinate
point.
Enter/
Select PT#
4 Set with {ENT} key.
{ENT}
5 Enter an instrument height.
Enter
instrument
height
6 Set with {ENT} key.
 Then, the procedure will move onto backsight
setting.
{ENT}
Operating procedure Operation Display
1 Select {F1} (INST SETUP).
{F1}
2 Select {F2} (CREATE INST PT).
{F2}
3 Enter the coordinate point of a occupied point and
its description.
Enter PT#,
Enter
DESC
4 Set with {ENT} key.
{ENT}
ENTER INST PT
PT#: [ ]
↑ ↓ ALP CLR
ENTER INST PT
PT#: [OCC-PT ]
↑ ↓ ALP CLR
ENTER INST HT
INST HT
=0.000_ m
CLR
ENTER INST HT
INST HT
=1.500_ m
CLR
1.SELECT BS PT
2.CREATE BS PT
3.BS DIRECTION
[1] [2] [3]
1.INST SETUP
2.LAYOUT
3.TOPO
[1] [2] [3]
1.SELECT INST PT
2.CREATE INST PT
3.MEAS KNWN PTS
[1] [2] [3]
ENTER NEW POINT:
PT#: [_ ]
DESC: [ ]
ALP CLR
ENTER NEW POINT:
PT#: [OCC ]
DESC: [POINT_ ]
ALP CLR
N [ ]
E [ ]
Z [ ]
ALP CLR
