19-6
19 TOP FIELD MODE
 Seeking an occupied point from existing coordinate data
5 Enter occupied point coordinates (N, E, Z).
Enter occu-
pied point
coordinate
6 Set with {ENT} key.
{ENT}
7 Enter an instrument height.
Enter
instrument
height
8 Set with {ENT} key.
 Then, the procedure will move onto backsight
setting.
{ENT}
Operating procedure Operation Display
1 Select {F1} (INST SETUP).
{F1}
2 Select {F3} (MEAS KNWN PTS).
{F3}
3 Enter an instrument height.
Enter
instrument
height
4 Set with {ENT} key.
{ENT}
5 Enter point number to collimate.
 Collimate point number: 2 to 7 points
Enter colli-
mate point
number
6 Set with {ENT}.
{ENT}
N [0.000 ]
E [0.000 ]
Z [0.000 ]
ALP CLR
ENTER INST HT
INST HT
=0.000_ m
CLR
ENTER INST HT
INST HT
=1.500_ m
CLR
1.SELECT BS PT
2.CREATE BS PT
3.BS DIRECTION
[1] [2] [3]
1.INST SETUP
2.LAYOUT
3.TOPO
[1] [2] [3]
1.SELECT INST PT
2.CREATE INST PT
3.MEAS KNWN PTS
[1] [2] [3]
ENTER INST HT
INST HT
=0.000_ m
CLR
ENTER INST HT
INST HT
=1.500_ m
CLR
ENTER # REF PTS
# REF PTS: =
CLR
ENTER # REF PTS
# REF PTS: = 2
CLR
ENTER TARGET HT
HT OF ROD
=0.000_ m
CLR
